Product Description: This machine uses a Husqvama K1270R engine imported from Sweden and is suitable for cutting rails weighing 43-75 kg/m. The rail clamping mechanism is equipped with automatic locking buckles, ensuring excellent stability and verticality. The main unit and rail clamping mechanism can be disassembled for portability. When the engine and cutter bracket are disassembled, the main unit will not start, effectively preventing accidental engine startup due to misoperation. The indicator uses nighttime fluorescence calibration, making it easy to align the cutting line. It features a compact size, lightweight, safe operation, accurate positioning, fast cutting speed, and high cross-sectional accuracy. It is an essential tool for railway maintenance and line overhaul, maintenance, and emergency repair work.
This product has passed CRCC railway product certification
| Main technical parameters | |
| Gasoline engine rated power | 5.8kW |
| Grinding wheel |
The maximum permissible speed of double-layer reinforced wire mesh is 5380r/min φ305×3.6×22.23 φ356×4×25.4 Maximum linear speed is less than 100m/s |
| Rated speed | 4950-5000r/min |
| Cutting accuracy |
a. The vertical deviation between the cut section and the longitudinal axis of the rail is not greater than 0.40mm b. The flatness deviation of the bidirectional cutting interface is no more than 0.35mm |
| Cutting time | Cut off60kg/m Rails no larger than2 Minute |
| Machine quality | ≤ 32kg |
| Fuel tank capacity | 1.25L |
| Overall size | 850×480×500(mm) |
| ISO9001 | 2015 Certification |
